If you try to open the newly created nwc file and get a popup message that says "File.nwc has an unknown version number" you will need to export or save the file in the correct version of Navisworks that you need.įor example if you are using the Revit 2016 add-in to export to Navisworks you can only open the generated nwc file in Navisworks 2016.

Then change the Export > Change this to Entire Project.

On the right side of the dialog box find the Coordinates pull down and set it to Project Internal do not select shared.

In the Navisworks Options Editor - Revit dialog box expand File Readers> and click on Revit. dialog box, click on the Navisworks Settings.button to open the Navisworks Options Editor - Revitĥ.

Go to the External Tools drop down menu and click on Navisworks to start the export command.Verify in your project that your Revit links were all brought in using origin to origin.You will need to change your export to Navisworks settings. when you review your project inside Revit you notice that it seem perfectly lined up. Need to Export from Revit to Navisworks Dont own Navisworks though You can download the Exporter you need for free, well free in, youll still have to. When you export your Revit model to Navisworks and open up the file and append the exported Revit link models, you notice that the objects are not lined up properly almost like the different Revit files have different coordinates.
